Scan to Revit BIM Modeling for a School Building

Project Objective

To create a 3D BIM model of an existing school building in Revit from the scan data. The client provided us with the scan data.

Client Summary

The company for which we completed the project is a reputed contracting firm in the UK.

Project Deliverables

  • Detailed Revit 3D model

Project Summary

The project required creating a Revit Model for the existing school building at LOD 300 with an area of approximately 8800 square meters. The client provided us with the scan data through the cloud server and we had to execute the project in Revit 2021.

Disciplines: Architecture & Structure Modeling

No. of floors: Approx. 4 (2 Blocks – Basement + 3)

Elements that were to be modeled:

  • All visible structural elements (walls, columns, slabs, beams, roof, roof elements, floor, stairs, ladders, ramps)
  • Ceiling
  • Partitions
  • Curtain walls
  • Windows
  • Doors
  • Elevator shafts
  • Openings
  • Railings

About Us

BIM Services India is a leading BIM Drafting Company in India since 15+ years which offers comprehensive services like Revit Modeling Services, Scan to BIM Services, Architectural, Structural & MEP BIM Services, 3D Rendering Services etc. Visit our samples page for more examples of our executed projects.
